    CO2 Fractional Laser Before and After

    author: Jingyue Beauty
    2025-09-22

    A Comprehensive Overview of CO2 Fractional Laser: Skin Resurfacing Before and After Results

    CO2 fractional laser skin resurfacing is a highly effective dermatological procedure known for its ability to rejuvenate skin, address various concerns, and promote collagen remodeling. The most compelling evidence of its efficacy comes from the dramatic fractional laser before and after transformations seen across a wide range of skin conditions. These visual testimonials showcase the significant improvements in skin texture, tone, and overall appearance that patients can expect.

    Below, we present several common skin problems and their corresponding co2 fractional laser before and after treatment results. The treatment parameters provided are commonly used and accepted in our practice, though adjustments should be made according to individual client needs.

    1. Anti-Aging, Skin Rejuvenation, and Skin Resurfacing Treatment Before and After

    For full-face resurfacing, fractional mode is typically used. The remarkable co2 fractional laser skin resurfacing before and after results demonstrate a visible reduction in fine lines, wrinkles, and overall skin laxity, leading to a more youthful complexion.
    • Technique: Standard fractional mode
    • Spot energy: 20–40 mJ
    • Laser power: 10–20 W
    • Spot spacing: 0.8–1.0 mm
    • Pulse width: 1–2 ms (shorter pulse width reduces carbonization and improves safety)
    For milder rejuvenation, lower spot energy (10–15 mJ) with 1 mm spacing is sufficient.
    One pass is usually effective, but an additional pass with a 45° rotation may be applied for lax skin.
    Treatments can also be performed on areas like the pre-auricular region where fine wrinkles appear.

    Treatment Sessions: Sessions are recommended every 3–6 months, depending on age, skin type, and recovery. Ideal treatment periods are from October to April in temperate and subtropical regions.
    Post-treatment: Functional ingredients such as copper peptides, PDRN, growth factors, astaxanthin, and nourishing serums can enhance results.

    2. Under-Eye Wrinkles and Dark Circles Treatment Before and After

    The delicate under-eye area shows significant improvement in co2 fractional laser before and after photos, with a reduction in fine lines  and a brightening of dark circles.

    • Technique: Rectangular or elliptical fractional pattern
    • Laser power: 8–10 W
    • Spot spacing: 0.8 mm
    • Pulse width: 1 ms
    • Spot energy: <10 mJ

    Crow’s feet areas can be treated with a pulse width of up to 2 ms.

    fractional laser before and after​
    Treatment Sessions: Recommended every 3 months with careful inflammation and PIH management.
    Post-treatment:mild edema, tearing, or discharge may occur. Functional ingredients like copper peptides and PDRN are beneficial. Use of Q10-enriched eye creams can improve microcirculation.

     3. Acne and Acne Scar Treatment Before and After

    CO2 laser effectively treats active acne and, more notably, improves the appearance of atrophic acne scars. The co2 fractional laser before and after comparisons reveal smoother skin texture and minimized scarring.

    • Technique: Combination of fractional and normal (cutting, pulse mode) modes.
    • Power: 15–20 W
    • Pulse width: 2–4 ms
    • Spot energy: 30–60 mJ
    • Spot spacing: 0.6–0.8 mm for inflamed areas

    Two passes are often used. For nodulocystic acne, manual extraction or cutting mode-assisted drainage may be necessary. Full-face treatment ensures even toning.

    fractional laser before and after​
    Treatment Sessions: Sessions can be repeated every 1–2 months.
    Post-treatment: Using collagen, growth factors, and hyaluronic acid aid recovery. Salicylic acid is also helpful.

    4. Scar and Stretch Mark Treatment Before and After

    CO2 fractional laser before and after images for hypertrophic scars, atrophic scars, and stretch marks show a noticeable improvement in skin texture and a reduction in the visibility of these imperfections.

    1) Hypertrophic Scars: Treated with high-density ablation (0.4 mm spacing) or handpiece vaporization.

    2) Atrophic Scars: Treated with higher energy (40–60 mJ) and dense spacing (0.4–0.6 mm) at the edges to stimulate collagen. Mild bleeding indicates good response. Subcision may be combined.

    3)For stretch marks:

    • Energy: 20–30 W
    • Pulse width: 2–4 ms
    • Spot energy: 60–90 mJ

    Normal mode(cutting) may be used for reinforcement

    fractional laser before and after​
    Treatment Sessions: Sessions every 2–3 months.
    Post-treatment: Using bFGF initially, then switch to KGF and type III collagen. Avoid friction.

    5. Xanthelasma Treatment Before and After

    The co2 fractional laser before and after results for xanthelasma demonstrate the precise vaporization and removal of these benign growths.

    Xanthelasma is treated with vaporization using a normal mode(cutting):

    • Technic: Repeat pulse or single pulse mode
    • Power: 3–5 W
    • Pulse width: 10 ms
    • Spot energy: 30–50 mJ

    Lidocaine can be used for analgesia. Avoid overtreatment to prevent scarring.


    fractional laser before and after​

    6. Syringoma and Flat Wart Treatment Before and After

    Similar to xanthelasma, the co2 fractional laser before and after outcomes for syringoma and flat warts show effective lesion clearance.

    • Technic: Repeat pulse or single pulse mode
    • Power: 3–5 W
    • Pulse width: 10 ms
    • Spot energy: 30–50 mJ

    Syringoma should be leveled flush with the skin to avoid scarring. Flat warts may indicate low immunity; antiviral agents or interferon may be needed.

    Smoke evacuation and protective gear (N95 mask, goggles) are essential.

    fractional laser before and after​

    7.Porokeratosis Treatment Before and After

    CO2 fractional laser before and after photos for porokeratosis illustrate the successful treatment of these lesions, leading to clearer skin.
    • Often treated with fractional mode
    • Power: 20 W
    • Spot spacing: 0.4–0.5 mm
    • Two passes per area

    Normal mode(cutting) should be used cautiously. IPL or Q-switched lasers are alternatives.

    fractional laser before and after​
    Post-treatment: Using L-ascorbic acid, chemical peels, and collagen products to support barrier repair.

    8.Seborrheic Keratosis and Pigmented Lesions Treatment Before and After

    The co2 fractional laser before and after evidence for pigmented lesions and seborrheic keratosis shows effective removal and a more even skin tone.
    Ablative or fractional mode can be used. Handpiece mode allows precise removal. Combine with IPL or Q-switched lasers for better results. Avoid accelerating scab removal.
    fractional laser before and after​
    Post-treatment, expect transient hyperpigmentation; use anti-pigment and anti-inflammatory agents.

    9. Intimate Feminine Treatment Before and After

    CO2 fractional laser before and after results in intimate areas demonstrate its efficacy for vaginal rejuvenation and labial remodeling.
    CO2 fractional laser is used for vaginal rejuvenation, labial remodeling, and color improvement. A 45° reflective handpiece with disposable sheath is used. Treatment starts deep in the vagina with rotational pulses, retreating gradually.
    Post-treatment: medical-grade hyaluronic acid or collagen aids recovery.
    Contact Us for A Free Consultation today

    Characteristics and Main Indications of CO2 Laser

    The CO2 laser is characterized by its high water absorption coefficient, which determines its depth of penetration in the skin. It primarily affects the epidermis and dermis, combining ablative vaporization with superficial dermal thermal coagulation. Depending on the application, the laser’s cutting and vaporization capabilities can be adjusted to remove skin tissue or growths effectively.

    The CO2 laser's effects can be summarized in two key aspects:

    • Ablative Vaporization: Removes damaged or unwanted tissue layer by layer..
    • Thermal Coagulation: Stimulates collagen production and skin tightening.

    Fractional CO2 laser is exceptionally versatile, with main indications including:

    • Overall skin rejuvenation and anti-aging
    • Treatment of most types of acne
    • Improvement of atrophic (depressed) acne scars
    • Removal of hypertrophic scars
    • Elimination of benign skin growths and tumors

    For excision-based treatments, a "repeated pulse" mode is often used with a handpiece.

    Managing Discomfort of CO2 Fractional Laser Before and After

    1)Is CO2 Laser Treatment Painful?

    CO2 laser treatment involves a noticeable heat-based discomfort, which is more pronounced in areas with thin skin or near nerve endings. On the face, the most sensitive areas include:

    • The region under the eyes (the infraorbital nerve exit)
    • Upper and lower eyelids
    • The forehead near the hairline
    • The perioral area (around the lips)

    Interestingly, the left side of the face often experiences more pain than the right.

    2)The Role of Topical Anesthesia

    Considering the CO2 laser treatment significant sensation of heat and dissatisfaction, which varies based on individual pain tolerance and the treatment area. Surface anesthesia should also be took into account in the treatment.

    While topical numbing creams are an option, they can sometimes cause allergic reactions or delay healing and re-epithelialization. There is also some belief that they may slightly inhibit the laser's rejuvenating effects. Therefore, for full-face anti-aging treatments, it is often recommended to proceed without topical anesthesia if the patient can tolerate the discomfort. The decision ultimately depends on the practitioner's assessment and the client's pain threshold.

    If topical anesthesia is used, it is advised to apply it for 40 minutes and then wipe it off completely. A spray containing dexamethasone mixed with saline or a collagen solution can be applied two minutes before treatment to help prevent adverse reactions.

    Contact Us for A Free Consultation Today

     Jingyue Beauty CO2 Fractional Laser Treatment

    Jingyue Beauty's CO2 Fractional Laser is a popular treatment device designed to address modern common skin issues. All the treatments and corresponding fractional laser before and after results mentioned above can be achieved with our equipment. All treatment modes and parameters can be customized, and through years of practical application, our device has proven fully capable of effectively addressing real-world challenges, delivering satisfactory fractional laser resurfacing before and after outcomes for clients and ensuring sustainable returns for various institutions.
    Learn More About Jingyue CO2 Fractional Laser Machine

    The Conclusion of Fractional Laser Treatment Before and After

    CO2 fractional laser resurfacing offers versatile solutions for skin rejuvenation, acne, scars, pigmentation, and intimate health. As demonstrated by the extensive fractional laser skin resurfacing before and after evidence, this treatment produces significant, visible improvements. For optimal outcomes, follow prescribed protocols and maintain consistent aftercare. You can also contact us for your professional guidance.---Talk to Us Now
